OARS1-R005FI | Welwyn
Resistor, metal strip, SMD 3637, 5 mΩ, 2 W, ±1 %, OARS1-R005FI
Unit Price (€ / pc.)
0.6783 € *
Available: 1,900 pcs.
Total Price:
67.83 € *
Price list
Quantity
Price per unit*
100 pcs.
0.6783 €
500 pcs.
0.5712 €
1000 pcs.
0.5474 €
1900 pcs.
0.4998 €
3800 pcs.
0.4641 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD metal strip resistors, 2.0 W, 1.0 % tolerance, type TT electronics/Welwyn OARS1.
Open design, flexible connections; Rated load: 2.0 W. Tolerance: ±1.0 %. Temperature coefficient: ±20 ppm/°C. Inductance: max. 10 nH. Ambient temperatures: –55 to +160 °C. Dimensions: L 11.18, W 3.18, H 3.05 mm.
Type: 0R005
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Temperature coefficient | ±20 ppm/K | |
| Technology | metal strip | |
| Tolerance | ±1 % | |
| Design | SMD 3637 | |
| ohmic resistance | 5 mΩ | |
| Power | 2 W | |
| Height | 3.05 mm | |
| max. operating temperature | 160 °C | |
| min. operating temperature | -55 °C | |
| Length | 11.18 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85332100 |
| Country of origin | MX |
| Original Packaging | Reel with 3,800 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
