1428090000 | Weidmüller
Transfer module, 26 pole, 1 A, 125 V, 1428090000, RS SD26M HD UNC4.40 S
Unit Price (€ / pc.)
64.4504 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
64.45 € *
Price list
Quantity
Price per unit*
1 pcs.
64.4504 €
10 pcs.
59.9403 €
25 pcs.
56.9415 €
*incl. VAT plus shipping costs
Subject to prior sale
Transfer module, 1428090000, Weidmüller
Transfer module with terminal connector, High density SUB-D connector, 26-pin male connector, LP3R 5.08 mm, Screw connection.
Transfer module as interface with terminals and plug connector.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | transfer module | |
| Pin number | 26 pole | |
| Rated current | 1 A | |
| Rated voltage | 125 V | |
| Length | 55 mm | |
| Width | 70 mm | |
| Height | 71 mm | |
| Connection | screw connection |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369095 |
| Country of origin | PL |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
