0183380000 | Weidmüller

Disconnect/test-disconnect terminal block, screw connection, 0.5-4.0 mm², 10 A, 6 kV, blue, 0183380000

Order No.: 50P0172
EAN: 4008190125950
MPN:
0183380000
SAKR/35 2STB BL
Series: SAK-Reihe
0183380000 Weidmüller Series Terminals
Image may differ
Unit Price (€ / pc.)
12.8163 € *
Standard delivery time from the manufacturer is: 2 Weeks
Total Price:
12.82 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
12.8163 €

Test-disconnect terminal, 0183380000, Weidmüller

Disconnect and test-disconnect terminal block, screw connection, 4 mm², 400 V, 10 A, swiveling, cross-disconnect: none, integrated test socket: yes, TS 35, blue

The test disconnect terminal block is used to disconnect circuits for test and measurement purposes.

Technical specifications
Filter Property Value
Rated Voltage 400 V
Connection screw connection
Rated current 10 A
Version disconnect/test-disconnect terminal block
Width 6.5 mm
Height 42 mm
AWG cross-section AWG 26 to 12
Degree of soiling 3
Rated surge voltage 6 kV
Colour blue
Number of terminals 2
Length 40.5 mm
Cable cross-section 0.5-4.0 mm²
Logistics
Property Value
Country of origin RO
Customs tariff number 85369010
Compliance
Property Value
Substance description Lead
SVHC free No
Date of RoHS guidelines 3/31/15
RoHS conform Yes
