2549420000 | Weidmüller
Socket header, 3 pole, pitch 7.62 mm, straight, black, 2549420000
Order No.: 50P1544
EAN: 4050118558852
MPN:
2549420000
BVFL 7.62HP/03/180 BCF/08R SN BK BX
Unit Price (€ / pc.)
12.9948 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
12.99 € *
Price list
Quantity
Price per unit*
1 pcs.
12.9948 €
10 pcs.
12.1856 €
50 pcs.
11.4716 €
100 pcs.
10.9837 €
*incl. VAT plus shipping costs
Subject to prior sale
Socket strip, 2549420000, Weidmüller
180° female plug with energy and signal contacts in PUSH IN wire connection in 7.62 pitch. Fulfils the IEC 61800-5-1 requirement and for the energy contact UL 1059 ClassC 600 V. With adjustable, selflocking pusher for opening the contact point.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Orientation | straight | |
| Colour | black | |
| Rated voltage | 1000 V | |
| Connection | push-in | |
| Pin number | 3 pole | |
| contact surface | tin-plated | |
| Grid | 7.62 mm | |
| Version | socket header | |
| Number of rows | 1 | |
| Contact type | socket | |
| Rated current | 38 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
