2439940000 | Weidmüller
Pin header, 5 pole, pitch 2.5 mm, straight, black, 2439940000
Order No.: 53P1366
EAN: 4050118455113
MPN:
2439940000
SL 2.50/05/180G 3.2SN BK BX
Unit Price (€ / pc.)
1.2495 € *
Standard delivery time from the manufacturer is: 4 Weeks
Male connector, 2439940000, Weidmüller
Printed circuit board connector, closed side, THT solder termination, 2.50 mm, no. of poles: 5, 180°, 3.2 mm, tin-plated, black, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Colour | black | |
| contact surface | tin-plated | |
| Rated current | 6 A | |
| Grid | 2.5 mm | |
| Pin number | 5 pole | |
| Version | pin header | |
| Additional parts | equipped | |
| Orientation | straight | |
| Connection | PCB connection | |
| Contact type | pin | |
| Rated voltage | 320 V | |
| Number of rows | 1 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
