2439820000 | Weidmüller
Pin header, 9 pole, pitch 2.5 mm, angled, black, 2439820000
Order No.: 53P1359
EAN: 4050118454994
MPN:
2439820000
SL 2.50/09/90G 3.2SN BK BX
Unit Price (€ / pc.)
1.9278 € *
Standard delivery time from the manufacturer is: 4 Weeks
Male connector, 2439820000, Weidmüller
Printed Circuit Board Connector, closed sideways, THT solder termination, 2.50 mm, no. of poles: 9, 90°, 3.2 mm, tinned, black, Box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 6 A | |
| contact surface | tin-plated | |
| Colour | black | |
| Additional parts | equipped | |
| Contact type | pin | |
| Grid | 2.5 mm | |
| Orientation | angled | |
| Rated voltage | 320 V | |
| Connection | PCB connection | |
| Pin number | 9 pole | |
| Version | pin header | |
| Number of rows | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369010 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
