1977210000 | Weidmüller
Pin header, 3 pole, pitch 3.81 mm, angled, black, 1977210000
Order No.: 52P8643
EAN: 4032248685226
MPN:
1977210000
SC-SMT 3.81/03/135G 3.2SN BK BX
Unit Price (€ / pc.)
1.2019 € *
Available: 47 pcs.
Total Price:
1.20 € *
Price list
Quantity
Price per unit*
1 pcs.
1.2019 €
250 pcs.
1.0829 €
1250 pcs.
0.9639 €
*incl. VAT plus shipping costs
Subject to prior sale
Male connector, 1977210000, Weidmüller
Board Connector, lateral closed, THT/THR solder termination, 3.81 mm, no. of poles: 3, 135°, 3.2 mm, tinned, black, Box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 3.81 mm | |
| Orientation | angled | |
| Connection | PCB connection | |
| Contact type | pin | |
| Rated current | 17.5 A | |
| Additional parts | equipped | |
| Version | pin header | |
| Pin number | 3 pole | |
| contact surface | tin-plated | |
| Number of rows | 1 | |
| Colour | black | |
| Rated voltage | 320 V |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
