1966910000 | Weidmüller
Pin header, 9 pole, pitch 10.16 mm, straight, black, 1966910000
Order No.: 52P8239
EAN: 4032248659890
MPN:
1966910000
SUZ 10.16HP/09/180G AG BK BX
Unit Price (€ / pc.)
24.4307 € *
Standard delivery time from the manufacturer is: 4 Weeks
Male connector, 1966910000, Weidmüller
PCB connector, closed side, 10.16 mm, no. of poles: 9, silver plated, black, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | pin header | |
| contact surface | silver-plated | |
| Pin number | 9 pole | |
| Rated voltage | 1 kV | |
| Orientation | straight | |
| Contact type | pin | |
| Grid | 10.16 mm | |
| Number of rows | 1 | |
| Additional parts | equipped | |
| Connection | screw connection | |
| Rated current | 78 A | |
| Colour | black |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | RO |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
