1959570000 | Weidmüller
Socket header, 20 pole, pitch 5 mm, angled, black, 1959570000
Order No.: 50P5383
EAN: 4032248638505
MPN:
1959570000
BLZP 5.00HC/20/90F SN BK BX
Unit Price (€ / pc.)
15.3272 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
15.33 € *
Price list
Quantity
Price per unit*
1 pcs.
15.3272 €
10 pcs.
14.2919 €
50 pcs.
13.3875 €
100 pcs.
12.5783 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB plug-in connector, 1959570000, Weidmüller
Female plug with clamping-yoke connection for connecting wire with a right-angle (90° or 270°) outlet direction. The female connector provides space for labelling and can be coded. Fastened by means of a flange or release latch. It also provides an integrated plus/minus screw, protection against faulty insertion of the wire, and is delivered with an open clamping yoke.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Connection | pull-bar connection | |
| Rated current | 23 A | |
| Orientation | angled | |
| Rated voltage | 400 V | |
| contact surface | tin-plated | |
| Contact type | socket | |
| Version | socket header | |
| Grid | 5 mm | |
| Number of rows | 1 | |
| Pin number | 20 pole |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | RO |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
