1949820000 | Weidmüller
Pin header, 4 pole, pitch 5.08 mm, angled, orange, 1949820000
Order No.: 52P7583
EAN: 4032248627745
MPN:
1949820000
BLZP 5.08HC/04/90F SN OR BX
Unit Price (€ / pc.)
3.8556 € *
Available in 6 Days: 120 pcs. - if ordered today
Total Price:
3.86 € *
Price list
Quantity
Price per unit*
1 pcs.
3.8556 €
10 pcs.
3.5938 €
50 pcs.
3.2249 €
*incl. VAT plus shipping costs
Subject to prior sale
Male connector, 1949820000, Weidmüller
PCB connector, male header, flange, 5.08 mm, no. of poles: 4, tinned, orange, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of rows | 1 | |
| Grid | 5.08 mm | |
| Orientation | angled | |
| Pin number | 4 pole | |
| Connection | screw connection | |
| Colour | orange | |
| Rated current | 23 A | |
| Additional parts | equipped | |
| Contact type | socket | |
| Version | socket header | |
| contact surface | tin-plated | |
| Rated voltage | 400 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
