1947490000 | Weidmüller
Pin header, 3 pole, pitch 10.16 mm, straight, black, 1947490000
Order No.: 52P7394
EAN: 4032248623778
MPN:
1947490000
SUZ 10.16HP/03/180G AG BK BX
Unit Price (€ / pc.)
8.0682 € *
Standard delivery time from the manufacturer is: 4 Weeks
Male connector, 1947490000, Weidmüller
PCB Connector, lateral closed, 10.16 mm, no. of poles: 3, silver plated, black, Box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| contact surface | silver-plated | |
| Rated current | 78 A | |
| Grid | 10.16 mm | |
| Pin number | 3 pole | |
| Version | pin header | |
| Additional parts | equipped | |
| Orientation | straight | |
| Connection | screw connection | |
| Contact type | pin | |
| Rated voltage | 1 kV | |
| Number of rows | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | RO |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
