1944140000 | Weidmüller
Pin header, 7 pole, pitch 5.08 mm, straight, orange, 1944140000
Order No.: 52P7234
EAN: 4032248618729
MPN:
1944140000
BLZP 5.08HC/07/180F SN OR BX
Unit Price (€ / pc.)
6.0809 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
6.08 € *
Price list
Quantity
Price per unit*
1 pcs.
6.0809 €
10 pcs.
5.6525 €
50 pcs.
5.1527 €
*incl. VAT plus shipping costs
Subject to prior sale
Male connector, 1944140000, Weidmüller
Printed circuit board connector, male connector, flange, 5.08 mm, no. of poles: 7, tinned, orange, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | screw connection | |
| Colour | orange | |
| Additional parts | equipped | |
| Pin number | 7 pole | |
| Contact type | socket | |
| Orientation | straight | |
| Rated voltage | 400 V | |
| contact surface | tin-plated | |
| Version | socket header | |
| Rated current | 23 A | |
| Number of rows | 1 | |
| Grid | 5.08 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
