1931900000 | Weidmüller
Plug, 10 pole, pitch 7.62 mm, straight, black, 1931900000
Order No.: 50P0749
EAN: 4032248581924
MPN:
1931900000
SVZ 7.62HP/10/180F SN BK BX
Unit Price (€ / pc.)
19.3375 € *
Standard delivery time from the manufacturer is: 9 Weeks
Total Price:
19.34 € *
Price list
Quantity
Price per unit*
1 pcs.
19.3375 €
10 pcs.
17.3978 €
25 pcs.
16.3149 €
50 pcs.
15.3510 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB plug-in connector, 1931900000, Weidmüller
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | black | |
| Connection | tension clamp connection | |
| Contact type | pin | |
| contact surface | tin-plated | |
| Grid | 7.62 mm | |
| Number of rows | 1 | |
| Orientation | straight | |
| Version | plug housing | |
| Rated current | 57 A | |
| Pin number | 10 pole | |
| Rated voltage | 1000 V |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
