1863150000 | Weidmüller
Pin header, 3 pole, pitch 3.81 mm, angled, black, 1863150000
Order No.: 52P3689
EAN: 4032248428342
MPN:
1863150000
SC-SMT 3.81/03/90G 1.5SN BK RL
Unit Price (€ / pc.)
1.1424 € *
Standard delivery time from the manufacturer is: 9 Weeks
Male connector, 1863150000, Weidmüller
PCB Connector, Side-Closed, THT/THR Solder Termination, 3.81 mm, Pole Number: 3, 90°, 1.5 mm, Tin Plated, Black, Tape (Ø 330 mm); Rs = 10
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| contact surface | tin-plated | |
| Grid | 3.81 mm | |
| Connection | PCB connection | |
| Number of rows | 1 | |
| Pin number | 3 pole | |
| Orientation | angled | |
| Rated voltage | 320 V | |
| Version | pin header | |
| Rated current | 17.5 A | |
| Additional parts | equipped | |
| Colour | black | |
| Contact type | pin |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
