1726360000 | Weidmüller
Pin header, 20 pole, pitch 5.08 mm, angled, orange, 1726360000
Order No.: 50P4166
EAN: 4032248061334
MPN:
1726360000
SLD 5.08V/20/90B 3.2 SN OR BX
Unit Price (€ / pc.)
8.8655 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
8.87 € *
Price list
Quantity
Price per unit*
1 pcs.
8.8655 €
10 pcs.
8.2586 €
50 pcs.
7.7350 €
100 pcs.
7.2709 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB plug-in connector, 1726360000, WEIDMÜLLER
PCB plug-in connector, male header, Dovetails for fixing blocks, THT solder connection, 5.08 mm, Number of poles: 20, 90°, Solder pin length (l): 3.2 mm, tinned, orange.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | orange | |
| Grid | 5.08 mm | |
| Number of rows | 2 | |
| contact surface | tin-plated | |
| Rated current | 17 A | |
| Connection | solder connection | |
| Version | pin header | |
| Orientation | angled | |
| Pin number | 20 pole | |
| Contact type | pin | |
| Rated voltage | 320 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366930 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
