1630480000 | Weidmüller
Pin header, 2 pole, pitch 5 mm, angled, orange, 1630480000
Order No.: 51P7961
EAN: 4008190203900
MPN:
1630480000
SL 5.00/02/135B 3.2SN OR BX
Unit Price (€ / pc.)
0.6307 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
0.63 € *
Price list
Quantity
Price per unit*
1 pcs.
0.6307 €
10 pcs.
0.5712 €
50 pcs.
0.5236 €
100 pcs.
0.4760 €
*incl. VAT plus shipping costs
Subject to prior sale
Male connector, 1630480000, Weidmüller
Printed Circuit Board Connector, Dovetails for Mounting Blocks, THT Solder Termination, 5.00 mm, No. of Poles: 2, 135°, 3.2 mm, Tin Plated, Orange, Box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | orange | |
| contact surface | tin-plated | |
| Rated current | 17 A | |
| Grid | 5 mm | |
| Pin number | 2 pole | |
| Version | pin header | |
| Additional parts | equipped | |
| Orientation | angled | |
| Connection | PCB connection | |
| Contact type | pin | |
| Rated voltage | 400 V | |
| Number of rows | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
