1629160000 | Weidmüller
Pin header, 5 pole, pitch 7.5 mm, straight, orange, 1629160000
Order No.: 51P7917
EAN: 4008190201968
MPN:
1629160000
SL 7.50/05/180B 3.2SN OR BX
Unit Price (€ / pc.)
1.9159 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
1.92 € *
Price list
Quantity
Price per unit*
1 pcs.
1.9159 €
10 pcs.
1.7493 €
50 pcs.
1.5946 €
100 pcs.
1.4399 €
*incl. VAT plus shipping costs
Subject to prior sale
Male connector, 1629160000, Weidmüller
PCB Connector, Dovetail for Mounting Blocks, THT Solder Termination, 7.50 mm, No. of Poles: 5, 180°, 3.2 mm, Tin Plated, Orange, Box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage | 800 V | |
| Orientation | straight | |
| Pin number | 5 pole | |
| Version | pin header | |
| Colour | orange | |
| Grid | 7.5 mm | |
| Rated current | 18.5 A | |
| Contact type | pin | |
| Number of rows | 1 | |
| Connection | PCB connection | |
| contact surface | tin-plated | |
| Additional parts | equipped |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
