1603250000 | Weidmüller
Pin header, 21 pole, pitch 5.08 mm, angled, orange, 1603250000
Order No.: 51P7261
EAN: 4008190112844
MPN:
1603250000
SL 5.08/21/135 3.2SN OR BX
Unit Price (€ / pc.)
6.6045 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
Total Price:
6.60 € *
Price list
Quantity
Price per unit*
1 pcs.
6.6045 €
10 pcs.
6.1523 €
50 pcs.
5.5811 €
*incl. VAT plus shipping costs
**Subject to prior sale
Male connector, 1603250000, Weidmüller
Printed Circuit Board Connector, male header, side open, THT solder termination, 5.08 mm, no. of poles: 21, 135°, 3.2 mm, tinned, orange, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Colour | orange | |
| contact surface | tin-plated | |
| Rated current | 17 A | |
| Grid | 5.08 mm | |
| Pin number | 21 pole | |
| Version | pin header | |
| Additional parts | equipped | |
| Orientation | angled | |
| Connection | PCB connection | |
| Contact type | pin | |
| Rated voltage | 400 V | |
| Number of rows | 1 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
