1603150000 | Weidmüller
Pin header, 11 pole, pitch 5.08 mm, angled, orange, 1603150000
Order No.: 51P7251
EAN: 4008190011673
MPN:
1603150000
SL 5.08/11/135 3.2SN OR BX
Unit Price (€ / pc.)
5.6644 € *
Available in 5 Days: 150 pcs. - if ordered today
Male connector, 1603150000, Weidmüller
Printed circuit board connectors, male connector, open sideways, THT solder termination, 5.08 mm, no. of poles: 11, 135°, 3.2 mm, tinned, orange, Box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 5.08 mm | |
| Pin number | 11 pole | |
| Colour | orange | |
| Contact type | pin | |
| Rated current | 17 A | |
| Version | pin header | |
| Connection | PCB connection | |
| Additional parts | equipped | |
| Number of rows | 1 | |
| Rated voltage | 400 V | |
| contact surface | tin-plated | |
| Orientation | angled |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
