1465210000 | Weidmüller
Socket header, 8 pole, pitch 5.08 mm, angled, green, 1465210000
Order No.: 50P2838
EAN: 4050118271966
MPN:
1465210000
BLL 5.08/08/90FI 3.2SN GN BX
Unit Price (€ / pc.)
4.9385 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
4.94 € *
Price list
Quantity
Price per unit*
1 pcs.
4.9385 €
10 pcs.
4.6053 €
50 pcs.
4.3078 €
100 pcs.
4.0579 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB plug-in connector, 1465210000, WEIDMÜLLER
PCB plug-in connector, female header, Inverted flange, THT solder connection, 5.08 mm, Number of poles: 8, 90°, Solder pin length (l): 3.2 mm, tinned, Pale green.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Colour | green | |
| Number of rows | 1 | |
| Connection | solder connection | |
| Rated voltage | 400 V | |
| Orientation | angled | |
| contact surface | tin-plated | |
| Version | socket header | |
| Pin number | 8 pole | |
| Contact type | pin | |
| Grid | 5.08 mm | |
| Rated current | 23 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366930 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
