1173690000 | Weidmüller
Pin header, 3 pole, pitch 7.62 mm, angled, black, 1173690000
Order No.: 50P7788
EAN: 4032248966493
MPN:
1173690000
SL 7.62IT/03/90MF3 3.2SN BK BX
Unit Price (€ / pc.)
2.0111 € *
Standard delivery time from the manufacturer is: 9 Weeks
Total Price:
2.01 € *
Price list
Quantity
Price per unit*
1 pcs.
2.0111 €
10 pcs.
1.8445 €
50 pcs.
1.6660 €
*incl. VAT plus shipping costs
Subject to prior sale
Male connector, 1173690000, Weidmüller
PCB connector, side mount, center flange, THT solder termination, 7.62 mm, no. of poles: 3, 90°, 3.2 mm, tin plated, black, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Colour | black | |
| contact surface | tin-plated | |
| Rated current | 29 A | |
| Grid | 7.62 mm | |
| Pin number | 3 pole | |
| Version | pin header | |
| Additional parts | equipped | |
| Orientation | angled | |
| Connection | PCB connection | |
| Contact type | pin | |
| Rated voltage | 630 V | |
| Number of rows | 1 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
