1155650000 | Weidmüller
Pin header, 9 pole, pitch 5.08 mm, angled, black, 1155650000
Order No.: 50P7300
EAN: 4050118050288
MPN:
1155650000
SL 5.08HC/09/90B 3.2SN BK BX
As a private customer, you can buy this item as soon as we have it back in stock.
PCB plug-in connector, 1155650000, Weidmüller
Printed Circuit Board Connector, Male Connector, Dovetails for Mounting Blocks, THT Solder Termination, 5.08 mm, No. of Poles: 9, 90°, 3.2 mm, Tinned, black
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| contact surface | tin-plated | |
| Number of rows | 1 | |
| Contact type | pin | |
| Colour | black | |
| Pin number | 9 pole | |
| Grid | 5.08 mm | |
| Orientation | angled | |
| Rated voltage | 400 V | |
| Additional parts | equipped | |
| Rated current | 24 A | |
| Connection | PCB connection | |
| Version | pin header |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
