1060510000 | Weidmüller
Socket header, 3 pole, pitch 7.62 mm, straight, black, 1060510000
Order No.: 50P4361
EAN: 4032248810024
MPN:
1060510000
BVF 7.62HP/03/180SF SN BK BX
Unit Price (€ / pc.)
5.7239 € *
Standard delivery time from the manufacturer is: 10 Weeks
Total Price:
5.72 € *
Price list
Quantity
Price per unit*
1 pcs.
5.7239 €
10 pcs.
5.3193 €
50 pcs.
4.8552 €
*incl. VAT plus shipping costs
Subject to prior sale
Female connector, 1060510000, Weidmüller
PCB connectors, screw / snap-in flange, 7.62 mm, no. of poles: 3, tin-plated, black, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Orientation | straight | |
| Colour | black | |
| Rated voltage | 1 kV | |
| Connection | spring connection | |
| Pin number | 3 pole | |
| contact surface | tin-plated | |
| Additional parts | equipped | |
| Grid | 7.62 mm | |
| Version | socket header | |
| Number of rows | 1 | |
| Contact type | socket | |
| Rated current | 57 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
