1026840000 | Weidmüller
Pin header, 5 pole, pitch 7.62 mm, angled, orange, 1026840000
Order No.: 50P3077
EAN: 4032248752331
MPN:
1026840000
SL 7.62HP/05/90F 3.2 SN OR BX
Unit Price (€ / pc.)
2.8441 € *
Standard delivery time from the manufacturer is: 7 Weeks
Total Price:
2.84 € *
Price list
Quantity
Price per unit*
1 pcs.
2.8441 €
10 pcs.
2.6299 €
50 pcs.
2.3800 €
*incl. VAT plus shipping costs
Subject to prior sale
Male connector, 1026840000, Weidmüller
Printed Circuit Board Connector, flange, THT solder termination, 7.62 mm, no. of poles: 5, 90°, 3.2 mm, tinned, orange, box
Pluggable PCB connector with innovative connection technology for safe and intuitive handling.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 7.62 mm | |
| Orientation | angled | |
| Connection | PCB connection | |
| Contact type | pin | |
| Rated current | 29 A | |
| Additional parts | equipped | |
| Version | pin header | |
| Pin number | 5 pole | |
| contact surface | tin-plated | |
| Number of rows | 1 | |
| Colour | orange | |
| Rated voltage | 630 V |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
