1306070000 | Weidmüller

Polyester enclosure, (L x W x H) 90 x 220 x 220 mm, gray (RAL 7001), IP67, 1306070000

Order No.: 51P0771
EAN: 4050118108385
MPN:
1306070000
KLIPPON POK 122209 EX
Series: Klippon POK
1306070000 Weidmüller General Purpose Enclosures Image 1
1306070000 Weidmüller General Purpose Enclosures Image 2
Image may differ
Unit Price (€ / pc.)
94.8549 € *
Available in 6 Days: 5 pcs. - if ordered today
Total Price:
94.85 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
94.8549 €

Plastic enclosure, 1306070000, Weidmüller

The enclosure range of this product is made from a high-quality glass fibre reinforced polyester and is ideal for applications and environments where corrosion resistance, impact resistance and a high IP protection class are a requirement.

Features

  • Cover with stainless steel screws in cross-head / slotted design
  • Fixing holes outside the sealed area to ensure high ingress protection of IP66
  • Mounting directly in the enclosure or using an internal mounting plate
  • Direct wall mounting possible using fixing holes or mounting feet
  • Fastening thread to attach mounting rails and plates
Technical specifications
Degree of protection (IP) IP67
Length 90 mm
Colour gray
Width 220 mm
Height 220 mm
Material polyester
RAL number 7001
Logistics
Customs tariff number 85389099
Country of origin HU
Compliance
Substance description Lead
RoHS conform Yes
SVHC free No
Date of RoHS guidelines 3/31/15
