1195990000 | Weidmüller
Stainless steel enclosure, (L x W x H) 200 x 260 x 350 mm, silver (RAL 7035), IP67, 1195990000
Unit Price (€ / pc.)
1,362.8356 € *
Standard delivery time from the manufacturer is: 2 Weeks
Terminal box, 1195990000, Weidmüller
The 1195990000 provides excellent performance characteristics, even under the most difficult environmental conditions. In addition, it complies with the stricter requirements of potentially explosive atmospheres found specifically in the process or power generation industries.
Features
- The gasket is protected against compression
- Cover lock outside the sealed zone
- Improved temperature performance
- Earthing stud in the cover and base of the enclosure
- Welded mounting feet
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Width | 260 mm | |
| Colour | silver | |
| Degree of protection (IP) | IP67 | |
| Length | 200 mm | |
| Material | stainless steel | |
| Height | 350 mm | |
| RAL number | 7035 |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369095 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
