8771430000 | Weidmüller
Relay coupler 1 Form C (NO/NC), 2 A, 24 V (DC), 8771430000
NCNR (non cancelable / non returnable)
Unit Price (€ / pc.)
77.3143 € *
Available in 6 Days: 5 pcs. - if ordered today
Relay coupler, 8771430000, Weidmüller
Relay coupler, 24 VDC ±20 %, Free-wheeling diode, 1 changeover contact (AgSnO), 2 A, M12 plug / socket A-coded, Relay coupler as mounted assembly consisting of plug-in relay and plug-in socket. Control and load circuit are galvanically isolated.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | relay coupler | |
| Contact type | 1 Form C (NO/NC) | |
| Rated current | 2 A | |
| Rated voltage (DC) | 24 V | |
| Connection | M12-connector | |
| Contact material | AgSnO | |
| Degree of protection (IP) | IP67 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85364190 |
| Country of origin | PL |
Compliance
| Property | Value |
|---|---|
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
