2476740000 | Weidmüller

Relay coupler 1 Form C (NO/NC), 270 Ω, 10 A, 12 V (DC), 2476740000

Order No.: 53P2133
EAN: 4050118496963
MPN:
2476740000
DRIKIT 12VDC 1CO LD/PB
Series: D-SERIES DRI
2476740000 Weidmüller Coupling Relays Image 1
2476740000 Weidmüller Coupling Relays Image 2
Image may differ
Unit Price (€ / pc.)
8.7584 € *
Available in 6 Days: 50 pcs. - if ordered today
Total Price:
8.76 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
8.7584 €

Relay coupler, 2476740000, Weidmüller

Relay coupler, 12 VDC, LED green, Free-wheeling diode, 1 changeover contact with test button (AgNi), 250 VAC, 10 A, Screw connection, Relay coupler as mounted assembly consisting of plug-in relay and plug-in socket. Control and load circuit are galvanically isolated.

Technical specifications
Connection screw connection
Coil resistance 270 Ω
Contact type 1 Form C (NO/NC)
Rated current 10 A
Contact material AgNi
Degree of protection (IP) IP20
Version relay coupler
Status display LED, green
Rated voltage (DC) 12 V
Logistics
Customs tariff number 85364190
Country of origin RO
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
