2476340000 | Weidmüller

Relay coupler 1 Form C (NO/NC), 270 Ω, 10 A, 12 V (DC), 2476340000

Order No.: 53P2121
EAN: 4050118496901
MPN:
2476340000
DRIKIT 12VDC 1CO LD
Series: D-SERIES DRI
2476340000 Weidmüller Coupling Relays Image 1
2476340000 Weidmüller Coupling Relays Image 2
Image may differ
Unit Price (€ / pc.)
8.2348 € *
Available: 0 pcs.
Leadtime: 2 Weeks **
Total Price:
8.23 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
8.2348 €

Relay coupler, 2476340000, Weidmüller

Relay coupler, 12 VDC, LED green, Free-wheeling diode, 1 changeover contact (AgNi), 250 VAC, 10 A, Screw connection, Relay coupler as mounted assembly consisting of plug-in relay and plug-in socket. Control and load circuit are galvanically isolated.

Technical specifications
Rated voltage (DC) 12 V
Degree of protection (IP) IP20
Rated current 10 A
Version relay coupler
Connection screw connection
Contact type 1 Form C (NO/NC)
Contact material AgNi
Coil resistance 270 Ω
Status display LED, green
Logistics
Country of origin RO
Customs tariff number 85364190
Compliance
Date of RoHS guidelines 3/31/15
Substance description Lead
SVHC free No
RoHS conform Yes
