1123010000 | Weidmüller
Relay coupler 1 Form C (NO/NC), 24 V (DC), 6 A, 230 V (DC), 250 V (AC), 1123010000
Unit Price (€ / pc.)
16.4815 € *
Standard delivery time from the manufacturer is: 12 Weeks
Relay coupler, 1123010000, Weidmüller
Relay coupler, 24 V UC ±10 %, LED green, rectifier, 1 changeover contact (AgNi 5µm Au), 250 VAC, 6 A, Screw connection, Relay coupler as mounted assembly consisting of plug-in relay and plug-in socket. Control and load circuit are galvanically isolated.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Connection | screw connection | |
| Rated voltage (AC) | 250 V | |
| Rated voltage (DC) | 230 V | |
| Contact type | 1 Form C (NO/NC) | |
| Coil voltage (DC) | 24 V | |
| Degree of protection (IP) | IP20 | |
| Contact material | AgNi | |
| Product type | relay coupler | |
| Rated current | 6 A | |
| Status display | LED, green |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Customs tariff number | 85364900 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Substance description | Lead |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
