1016100000 | Weidmüller
Cable gland, PG21, 30 mm, Clamping range 11.5 to 15.5 mm, IP68, 1016100000
Order No.: 50P2652
EAN: 4032248725564
MPN:
1016100000
VG 21 HQ MS68 11.5-15.5
Unit Price (€ / pc.)
14.3633 € *
Standard delivery time from the manufacturer is: 3 Weeks
Cable gland, 1016100000, Weidmüller
Plastic cable gland for reliable sealing of cables with strain relief. This cable gland meets the most various IP protection classes to suit any industrial enclosure.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| max. clamping range | 15.5 mm | |
| min. clamping range | 11.5 mm | |
| spanner size | 30 mm | |
| Degree of protection (IP) | IP68 | |
| Thread size | PG21 | |
| Material | brass, nickel-plated | |
| max. operating temperature | 130 °C | |
| min. operating temperature | -40 °C | |
| Product type | cable gland |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 74122000 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Substance description | Lead |
| Date of RoHS guidelines | 3/31/15 |
