86872155 | Weco
PCB terminal, 5 pole, pitch 5 mm, AWG 18-12, 6 A, screw connection, gray, 86872155
Discontinued
Unit Price (€ / pc.)
2.3919 € *
Available: 1 pcs.
Total Price:
2.39 € *
Price list
Quantity
Price per unit*
1 pcs.
2.3919 €
25 pcs.
2.0349 €
100 pcs.
1.8683 €
250 pcs.
1.7850 €
1000 pcs.
1.6303 €
*incl. VAT plus shipping costs
Subject to prior sale
Plug-in screw connector systems for PCBs, type Weco
Socket terminal strip with solder pins, 5.0 mm grid, pin header with mating pins for the socket strip and screw terminal with wire protection; Plug-in direction: parallel to the PCB. Shell: tough polyamide, self-extinguishing, gray. Rated voltage: 630 V. Rated current: 6.0 A. Clamping range: to 2.5 mm² fine-wire. Thermal resistance: –40 to +80 °C (2- to 8-pole shell) or –40 to +100 °C (shell > 9 poles). Certifications: UL, CSA, SEV.
Plug-in screw connector for PCBs, type 971-SV.
Technical attributes (type, number of poles, length): 971-SV-DS/05, 5-pole, L 26 mm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 5 pole | |
| Grid | 5 mm | |
| Cable cross-section | 2.5 mm² | |
| AWG cross-section | AWG 18-12 | |
| Contact distance | RM 5/5.08 | |
| Rated current | 6 A | |
| Rated voltage | 630 V | |
| Connection | screw connection | |
| Colour | gray |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85369010 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
