10801502 | Weco
PCB terminal, 2 pole, pitch 5 mm, AWG 26-16, 16 A, screw connection, gray, 10801502
Discontinued
Unit Price (€ / pc.)
1.0591 € *
Available: 1 pcs.
Total Price:
1.06 € *
Price list
Quantity
Price per unit*
1 pcs.
1.0591 €
100 pcs.
0.9044 €
250 pcs.
0.8092 €
*incl. VAT plus shipping costs
Subject to prior sale
PCB screw connector, type Weco
With solder pins for PCB mounting and screw terminals with lift system. Dovetail interlocking feature for multi-pole assembly and different design.
Strip length: 10 mm
Shell: tough polyamide, self-extinguishing
PCB hole diameter: 1.2 mm
Rated cross-section: 1.5 mm²
Technical specifications
| Filter | Property | Value |
|---|---|---|
| AWG cross-section | AWG 26-16 | |
| Depth | 11.8 mm | |
| Pin number | 2 pole | |
| Colour | gray | |
| Cable cross-section | 0.14-2.5 mm² | |
| Connection | screw connection | |
| Grid | 5 mm | |
| Rated voltage | 300 V | |
| Rated current | 16 A | |
| Contact distance | RM 5/5.08 | |
| Height | 14.9 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
| Substance description | Lead |
