10806103 | Weco
Pin header, 3 pole, pitch 5.08 mm, angled, gray, 10806103
Discontinued
Unit Price (€ / pc.)
1.7612 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Total Price:
1.76 € *
Price list
Quantity
Price per unit*
1 pcs.
1.7612 €
100 pcs.
1.5827 €
400 pcs.
1.3804 €
*incl. VAT plus shipping costs
**Subject to prior sale
Pin headers with angled solder pins, 5.08 mm grid, type 121-M.
Insertion in parallel to the PCB. Color: gray. Operating current: 12 A. Operating voltage: 600 V. Test voltage: min. 2.5 kV. Soiling class: 2. Housing: PA 6.6, self-extinguishing to UL 94 V-0. Leakage current resistance (CTI): min 600. Thermal resistance: short-term +140 °C, permanent - 40 to + 80 °C. Female contacts: tin bronze, tinned. solder pins: 1.0 x 1.0 mm, tinned brass. Screw terminals: M 3, zinc-coated steel, chromalized yellow. Dimensions: length L = number of poles x grid. Standards and certifications: UL, CSA, etc.
Type: 111/03, 3-pole
Technical specifications
| Number of rows | 1 | |
| Breakable | No | |
| Rated voltage | 630 V | |
| Contact type | pin | |
| Type of locking | Yes | |
| Connection | PCB connection | |
| contact surface | tin-plated | |
| Pin number | 3 pole | |
| Grid | 5.08 mm | |
| Orientation | angled | |
| Additional parts | equipped | |
| Colour | gray | |
| Version | pin header | |
| Rated current | 12 A |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
