31830002 | Weco
Flat plug connector, 1 pole, 6.3 x 0.8 mm, L 11 mm, insulated, straight, transparent, 1.0-6.0 mm², AWG 16-10, 31830002
Discontinued
Unit Price (€ / pc.)
0.3332 € *
Available: 319 pcs.
Total Price:
6.66 € *
Price list
Quantity
Price per unit*
20 pcs.
0.3332 €
50 pcs.
0.3046 €
100 pcs.
0.2808 €
500 pcs.
0.2642 €
*incl. VAT plus shipping costs
Subject to prior sale
Flat plug connector, 31830002, Weco
The tab connector 31830002 is used mainly as connector, lead distributor or as electrical interface in equipment and motor vehicles. Crimped points can be insulated with ISO insulation sleeves. This tab connector is suitable for tab receptacles according to DIN 46247.
Technical specifications
| Insulation colour | transparent | |
| Nominal size according to DIN | DIN 46247 | |
| AWG cross-section | AWG 16-10 | |
| Cable cross-section | 1.0-6.0 mm² | |
| Connection | crimp connection | |
| Length | 11 mm | |
| Plug width x plug thickness | 6.3 x 0.8 mm | |
| shrinkable tubing | No | |
| Isolated | Yes | |
| Design | straight | |
| Version | flat plug connector, 1 pole | |
| Material | brass, nickel-plated |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
