Printed circuit board with 2x8 solder pads, 3 A, 250 V, 289-131
Unit Price (€ / pc.)
35.2954 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
35.30 € *
Price list
Quantity
Price per unit*
1 pcs.
35.2954 €
5 pcs.
31.7611 €
10 pcs.
29.5358 €
*incl. VAT plus shipping costs
Subject to prior sale
Rail-mountable serial modules for custom assembly, type 289-.
With wire entrance on the front and screw fastening, installation in mounting sockets, cage clamp terminals for 0.08 to 2.5 mm², Operating voltage: 250 VUC. Rated current: 3.0 A. Dimensions (LxWxH): 47.0x65.5x31.5 mm (H measured from top edge of the mounting rail). Corresponding mounting sockets 288-001 (for screw mounting) and combination sockets 288-002 for mounting rails are described below.
With 2 x 8 solder terminals, type 289-.
Grid: 5.0x12.0 mm. Solder terminals: fork-type.
Technical attributes (type, number of poles, grid, dimension L): 289–131, module with solder terminals
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Length | 62.5 mm | |
| Connection | spring-clamp connection | |
| Rated voltage | 250 V | |
| Rated current | 3 A | |
| Width | 42.5 mm | |
| Height | 32 mm | |
| Version | printed circuit board with 2x8 solder pads |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
