2001-1408 | WAGO
4-wire shield wire terminal, spring-clamp connection, 0.25-2.5 mm², 1 pole, 18 A, 8 kV, white, 2001-1408
Unit Price (€ / pc.)
3.4153 € *
Available: 84 pcs.
Available in 5 Days: 1,280 pcs. - if ordered today
4-Conductor shield terminal block, 2001-1408, Wago
4-conductor shielding conductor terminal block; 1.5 mm²; lateral and central labeling; for mounting rail 35 x 15 and 35 x 7.5; push-in CAGE CLAMP®; 1.50 mm²; white
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | 4-wire shield wire terminal | |
| Number of terminals | 4 | |
| Pin number | 1 pole | |
| Cable cross-section | 0.25-2.5 mm² | |
| AWG cross-section | AWG 22 to 14 | |
| Rated surge voltage | 8 kV | |
| Rated current | 18 A | |
| Rated Voltage | 800 V | |
| Degree of soiling | 3 | |
| Length | 32.9 mm | |
| Width | 4.2 mm | |
| Height | 69.9 mm | |
| Connection | spring-clamp connection | |
| Colour | white |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 39269097 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
