771-9293/117-201 | WAGO
Connection cable, 2 m, socket, 3 pole straight to open end, 2.5 mm², 771-9293/117-201
Connecting line, 771-9293/117-201, WAGO
The WINSTA MIDI Connecting line A coding. This pluggable installation connector is used when criteria repeat or is distributed on a defined pattern, for example for installing grid lighting or flush-mount lighting. The coding options reduce installation errors, allowing fast, maintenance-free wiring of all components. The pluggable installation connector offers touch-proof protection with live components in accordance with protection type IP20.
The Connecting line is provided with a socket and a free end. The WINSTA Pluggable Connection System is ideally tailored to the strict requirements of building installation. It makes electrical installation pluggable, and consequently faster, even more reliable, and error-free. Using this pre-assembled system decreases assembly times and installation errors at the construction site. Enjoy the benefits of the pluggable version of our maintenance-free spring pressure connection technology too!.
Features
- Effective protection against mismating
- For automation controllers
- For any mains application
- Flexible installation to save space
- Fast, secure installation
| Filter | Property | Value |
|---|---|---|
| Version | connection line | |
| Cable length | 2 m | |
| Connection (2) | open end | |
| Cable cross-section | 2.5 mm² | |
| Coding | A | |
| Connection (1) | socket, 3 pole | |
| Connection 1 design | straight |
| Property | Value |
|---|---|
| Customs tariff number | 85444290 |
| Country of origin | DE |
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
