771-9993/406-102 | WAGO
Device connection cable, Europe, plug, 3 pole, straight on schuko socket, straight, H05VV-F3G1.5 mm², white, 1 m, 771-9993/406-102
Device connection line, 771-9993/406-102, WAGO
Cable assembly WINSTA MIDI 3-pole. For greater protection in electrical installations, the pluggable installation connector is equipped with mechanical protection against mismating. The pluggable installation connector is protected in accordance with protection type IP20. The required safety requirements in connection with EU CPR are fully satisfied by this product through fire class E.
The WINSTA Pluggable Connection System is perfectly tailored to the very strict requirements of building installation. It makes electrical installation pluggable, and thus faster, even more reliable, and error-free. Using this pre-assembled system decreases time spent on assembly and installation errors at the construction site. Now you can also cut installation costs without compromising quality and safety: with protection against mismating eliminates the need for servicing and prevents unnecessary downtime.
Features
- Effective protection against mismating
- For automation controllers
- Suitable for any application
- Fast, secure installation
| Filter | Property | Value |
|---|---|---|
| Standard connection 2 | CEE (7) III | |
| Standard connection 1 | IEC 61535 | |
| Cable type | H05VV-F3G1.5 mm² | |
| Connection (1) | plug, 3 pole, straight | |
| Country code | Europe | |
| Cable length | 1 m | |
| Connection (2) | schuko socket, straight | |
| Colour | white | |
| Cable cross-section | 1.5 mm² | |
| Rated current | 16 A | |
| Version | power cord |
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85444290 |
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| RoHS conform | Yes |
