831-3109/037-000 | WAGO
1-wire female connector, 9 pole, pitch 7.62 mm, light gray, 831-3109/037-000
Unit Price (€ / pc.)
16.3625 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
16.36 € *
Price list
Quantity
Price per unit*
1 pcs.
16.3625 €
10 pcs.
14.7203 €
*incl. VAT plus shipping costs
Subject to prior sale
1-Conductor female connector, 831-3109/037-000, Wago
Female connector with locking latches 100 % mismating protected codable with coding lug light gray
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | socket header | |
| Pin number | 9 pole | |
| Breakable | No | |
| Rated voltage | 1000 V | |
| Contact type | socket | |
| Grid | 7.62 mm | |
| Number of rows | 1 | |
| Additional parts | equipped | |
| Connection | push-in | |
| Rated current | 41 A | |
| Colour | light gray |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
