769-123 | WAGO
Socket header, 3 pole, pitch 5 mm, straight, gray, 769-123
Unit Price (€ / pc.)
   6.5212 €  *
   Standard delivery time from the manufacturer is: 4 Weeks
 Total Price:
  6.52 € *
  Price list
 Quantity
 Price per unit*
 1 pcs.
 6.5212 €
 10 pcs.
 5.9976 €
 50 pcs.
 5.4621 €
 100 pcs.
 4.9147 €
  *incl. VAT plus shipping costs
  Subject to prior sale
 2-Conductor female connector, 769-123, Wago
2-conductor female connector for insertion into base terminals or pin headers, can be coded, can be bridged with cross and box jumpers 3-pole gray
 Technical specifications

 | Filter | Property | Value |
|---|---|---|
| Rated current | 32 A | |
| Colour | gray | |
| Additional parts | equipped | |
| Contact type | socket | |
| Grid | 5 mm | |
| Orientation | straight | |
| Rated voltage | 500 V | |
| Connection | spring-cage connection | |
| Pin number | 3 pole | |
| Version | socket header |
 Download
  Logistics

 | Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | PL |
 Compliance

 | Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
