722-206/026-000 | WAGO
Female connector, 6 pole, pitch 5 mm, angled, light gray, 722-206/026-000
Unit Price (€ / pc.)
5.4145 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
5.41 € *
Price list
Quantity
Price per unit*
1 pcs.
5.4145 €
10 pcs.
5.0932 €
*incl. VAT plus shipping costs
Subject to prior sale
1-conductor female connector, 722-206/026-000, WAGO
1-conductor female connector, angled, Cage clamp, 2.5 mm², Pin spacing 5 mm, 6-pole, 100% protected against mismating, 2.50 mm², light gray.
Features
- Universal connection for all conductor types
- Easy cable pre-assembly and on-unit wiring via vertical and horizontal Cage clamp actuation
- Integrated test ports
- 100% protected against mismating
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 5 mm | |
| contact surface | tin-plated | |
| Contact type | socket | |
| Connection | spring balancer connection | |
| Connection plating | tin-plated | |
| Rated voltage | 320 V | |
| Orientation | angled | |
| Number of rows | 1 | |
| Type of locking | No | |
| Pin number | 6 pole | |
| Colour | light gray | |
| Version | socket header | |
| Rated current | 14 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | PL |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
