721-111/027-000 | WAGO
Socket header, 11 pole, pitch 5 mm, angled, light gray, 721-111/027-000
Unit Price (€ / pc.)
8.1991 € *
Standard delivery time from the manufacturer is: 3 Weeks
Female header, 721-111/027-000, Wago
Multipoint connector with mounting flanges 11-pole Spacing 5 mm / 0.197 in 100 % mismating protected with stiffening strips codable with 2 locking lugs for plug-in units and feed-throughs for screw terminals or similar. Mounting types light gray
Technical specifications
| Type of locking | No | |
| contact surface | tin-plated | |
| Contact type | socket | |
| Additional parts | equipped | |
| Grid | 5 mm | |
| Pin number | 11 pole | |
| Number of rows | 1 | |
| Rated voltage | 320 V | |
| Connection | spring balancer connection | |
| Rated current | 16 A | |
| Version | socket header | |
| Colour | light gray | |
| Connection plating | tin-plated | |
| Orientation | angled |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
