232-871/047-000 | WAGO
Socket header, 11 pole, pitch 7.62 mm, angled, orange, 232-871/047-000
Unit Price (€ / pc.)
8.3538 € *
Available: 0 pcs.
Leadtime: On Request **
Female header, 232-871/047-000, Wago
Female connector with angled solder pins and spacer flanges 11-pin Spacing 7.62 mm / 0.3 in Solder pin 0.6x1 mm codable Mating direction perpendicular to printed circuit board with 2 detents for flush mounting of housings orange
Technical specifications
| Connection | Lötstift | |
| Connection plating | verzinnt | |
| Number of rows | 1 | |
| Version | Buchsenleiste | |
| Additional parts | bestückt | |
| Colour | orange | |
| Contact type | Buchse | |
| contact surface | verzinnt | |
| Rated voltage | 630 V | |
| Rated current | 12 A | |
| Orientation | abgewinkelt | |
| Pin number | 11-polig | |
| Grid | 7.62 mm | |
| Type of locking | Nein |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
