232-733/047-000 | WAGO

Socket header, 3 pole, pitch 7.5 mm, straight, gray, 232-733/047-000

Order No.: 43P7198
EAN: 4044918625777
MPN:
232-733/047-000
232-733/047-000 WAGO PCB Connection Systems Image 1
232-733/047-000 WAGO PCB Connection Systems Image 2
Image may differ
Unit Price (€ / pc.)
2.8203 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
2.82 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
2.8203 €

Female header, 232-733/047-000, Wago

Female connector with straight solder pins and spacer flanges 3 poles Spacing 7,5 mm / 0.295 in solder pin 0,6x1 mm codable Mating direction perpendicular to PCB only 1 detent for flush mounting of housing grey

Technical specifications
Filter Property Value
Connection plating tin-plated
Grid 7.5 mm
Orientation straight
Connection solder pin
Contact type socket
Rated current 12 A
Additional parts equipped
Version socket header
Pin number 3 pole
Type of locking No
contact surface tin-plated
Number of rows 1
Colour gray
Rated voltage 630 V
Logistics
Property Value
Country of origin DE
Customs tariff number 85366990
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
