2231-216/008-000 | WAGO
Socket header, 16 pole, pitch 7.5 mm, angled, gray, 2231-216/008-000
Unit Price (€ / pc.)
15.8032 € *
Standard delivery time from the manufacturer is: 4 Weeks
Total Price:
15.80 € *
Price list
Quantity
Price per unit*
1 pcs.
15.8032 €
10 pcs.
14.5418 €
50 pcs.
13.2328 €
100 pcs.
11.9119 €
*incl. VAT plus shipping costs
Subject to prior sale
Female header, 2231-216/008-000, Wago
Female connector with actuation pushers and test holes 16-pole grid dimension 7.5 mm / 0.295 in codable with 2 test holes plate thickness 0.6x1.2 mm mounting holes Ø 3.5 mm with mounting adapter 209-137 also on TS 35 gray
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 16 A | |
| contact surface | tin-plated | |
| Colour | gray | |
| Additional parts | equipped | |
| Contact type | socket | |
| Connection plating | tin-plated | |
| Grid | 7.5 mm | |
| Orientation | angled | |
| Rated voltage | 630 V | |
| Connection | spring balancer connection | |
| Pin number | 16 pole | |
| Version | socket header | |
| Type of locking | No | |
| Number of rows | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | PL |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
