2091-1524/002-000 | WAGO
Pin header, 4 pole, pitch 3.5 mm, straight, light gray, 2091-1524/002-000
Unit Price (€ / pc.)
4.1293 € *
Available: 137 pcs.
Total Price:
4.13 € *
Price list
Quantity
Price per unit*
1 pcs.
4.1293 €
10 pcs.
3.7961 €
50 pcs.
3.4510 €
100 pcs.
3.1059 €
*incl. VAT plus shipping costs
Subject to prior sale
Female connector, 2091-1524/002-000, WAGO
1-conductor male connector, Push-in CAGE CLAMP, 1.5 mm², pin spacing 3.5 mm, 4-pole, integrated release lever, 1,50 mm², light gray.
Features
- Universal connection for all conductor types
- Simple, push-in termination of solid and ferruled conductors
- Easy-to-use design does not require special tools
- Testing parallel to conductor entry - tip contact
- Integrated release lever
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 10 A | |
| Colour | light gray | |
| Additional parts | equipped | |
| Contact type | pin | |
| Grid | 3.5 mm | |
| Orientation | straight | |
| Rated voltage | 160 V | |
| Connection | push-in | |
| Breakable | No | |
| Pin number | 4 pole | |
| Version | pin header | |
| Number of rows | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85043180 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
