2091-1304/200-000 | WAGO
Socket header, 4 pole, pitch 3.5 mm, straight, light gray, 2091-1304/200-000
Unit Price (€ / pc.)
3.2606 € *
Standard delivery time from the manufacturer is: On Request
THR female header, 2091-1304/200-000, WAGO
THR female header, straight, Pin spacing 3.5 mm, 4-pole, 0.4 x 0.9 mm solder pin, light gray.
Features
- Coding pins inserted into the header interface prevent mismating, allowing subsequent coding in panel feedthrough applications
- The female connector is fully shrouded by the male header's housing, providing vibration resistance up to 20 g
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated current | 10 A | |
| contact surface | tin-plated | |
| Colour | light gray | |
| Contact type | socket | |
| Grid | 3.5 mm | |
| Orientation | straight | |
| Rated voltage | 160 V | |
| Connection | solder pin | |
| Pin number | 4 pole | |
| Version | socket header | |
| Type of locking | No | |
| Number of rows | 1 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | No |
| Date of RoHS guidelines | 3/31/15 |
