2091-1127 | WAGO
1-wire female connector, 7 pole, pitch 3.5 mm, straight, light gray, 2091-1127
Unit Price (€ / pc.)
3.7604 € *
Available: 90 pcs.
Available in 5 Days: 1,160 pcs. - if ordered today
Female connector, 2091-1127, WAGO
1-conductor female connector, push-button, Push-in CAGE CLAMP, 1.5 mm², pin spacing 3.5 mm, 7-pole, 1,50 mm², light gray.
Features
- Universal connection for all conductor types
- Simple, push-in termination of solid and ferruled conductors
- Easy-to-use design does not require special tools
- Ability to wire while mated or unmated
- Integrated locking latches prevent accidental disconnection
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Pin number | 7 pole | |
| Number of rows | 1 | |
| Version | socket header | |
| Grid | 3.5 mm | |
| Additional parts | equipped | |
| Contact type | socket | |
| Orientation | straight | |
| Rated voltage | 160 V | |
| Connection | push-in | |
| Colour | light gray | |
| Breakable | No | |
| Rated current | 10 A |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366990 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
