2022-114 | WAGO
Female connector, 14 pole, pitch 5.2 mm, gray, 2022-114
Unit Price (€ / pc.)
13.6850 € *
Standard delivery time from the manufacturer is: 3 Weeks
Total Price:
13.69 € *
Price list
Quantity
Price per unit*
1 pcs.
13.6850 €
10 pcs.
12.8639 €
*incl. VAT plus shipping costs
Subject to prior sale
1-conductor female connector, 2022-114, WAGO
1-conductor female connector, Push-in Cage clamp, 4 mm², Pin spacing 5.2 mm, 14-pole, 4.00 mm², gray.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 5.2 mm | |
| Breakable | No | |
| Contact type | socket | |
| Connection | spring-clamp connection | |
| Rated voltage | 690 V | |
| Number of rows | 1 | |
| Pin number | 14 pole | |
| Additional parts | equipped | |
| Colour | gray | |
| Version | female connector | |
| Rated current | 24 A |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | No |
